X,Y,Z working area

1300x2500x200mm

X,Y,Z Traveling positioning accuracy

±0.03/300mm

X,Y,Z Repositioning positioning accuracy

±0.03mm

Lathe bed frame

Steel square tubes

X,Y Structure

Rack and pinion, Taiwan HIWIN guide rails 20mm

Z Structure

Taiwan TBI Ball screw  2510Taiwan HIWIN guide rails 20mm

Drive motors

Hybrid servo motor and driver system

Table surface

vacuum table

Fixing method

vacuum

Max power comsumption

(without spindle)2.0KW

Max rapid travel rate

30000mm/min

Max working speed

20000mm/min

Spindle

air-cooling

Spindle power

4.5KW

Spindle speed

18000RPM

Working voltage

AC380V,50/60HZ,3Phase

Command language

G Code

Operatiing system

NC studio control system

Computer interface

USB

Collet

ER25(3.175/4/6/8/10/12.7mm)

X,Y Resolution

<0.02mm

Software compatiliby

Type3/Artcam/Artcut/Ucancam/JDpaint etc software

Running environment temperature

0-45 centigrade

Relative humidity

30%-75%

Weight

1400kg
