Advertising small 3D Cnc Router 6090 China MEIYA factory

Tel：+86 13176656080

Email：info@meiyacnc.com

WhatsApp：+86 13176656080

Product Details

Number	Description	Pparameter
1	XYZ working area	600900150mm
2	Table size	740*1120mm
3	XYZ travel positioning accuracy	±0.05mm
4	XYZ repositioning positioning accury	±0.05mm
5	Gantry	cast-aluminium
6	lathe structure	Square lathe tube
7	drive system X-Y axis	Ball screw Taiwan TBI
8	drive system Z axis	Ball screw Taiwan TBI
9	Spindle power	1.5KW water cooling spindle
10	Max velocity	8m/min
11	Max working speed	6m/min
12	Spindle speed	0-24000rmp
13	work mode	Stepper motor 450A
14	Working voltage	AC220V,50HZ
15	Command language	G code
16	Interface	USB
17	Operating system	Weihong DSPNK105
18	Inverter	Fuling inverter
19	X-Y resolution	0.025mm
20	Software	Artcam
21	Running environment	Temperature:0-45°C
22	Packing size	155011401450mm
23	Net weight	200kg
24	Gross weight	220kg

Application :
1) It is good at engraving on brass, aluminum, plastic, acrylic, wood, MDF and other similar materials , with fast speed and high accuracy,

and it can meet the demand of all the needs of engraving.

2)Especially for Advertising industry:

Advertising identification, sigh making, Acrylic engraving and cutting, Blaster molding, Crafts relief processing, PVC words,Light words,

Plastic words,Artwork,Aluminum,PCB,Various types of landmark model.
