Spindle type:

water cooling spindle

Spindle power

3kw

Spindle rotating speed

0-24000rpm

Power (except spindle power)

6.8KW (include powers of: motors, drivers, inverters and so on)

Power supply:

AC 380V, 50/60HZ,3 Phase (Optional 220V)

Worktable:

T-slot table

Locating precision:

<0.01mm

Min shaping character:

Character:3x3mm,letter:2x2mm

Operating temperature:

5°C-40°C

Working humidity

30%-75%(without condensed water)

Working precision

±0.03mm

System resolution

±0.001mm

Control configuration:

DSP control system

Data transfer interface:

USB/PC

System environment:

WINDOWS 2000/WINDOWS XP/ windows 7

Spindle cooling way:

By air fan

Graphic format supported:

G code: *.u00, * mmg, * plt, *.nc

Compatible software

ARTCAM(Optional UCANCAM ,Type3)

Cutting thickness:

0-40mm also (depends on different material)

Z tool censor:

yes

Whole machine dimension:

3170x2070x1800mm

Net weight:

1100KG

Gross weight

1300KG

packing

Plywood case (veneer wood case for export)

Optional parts

1. HSD Air cooled type spindle 2. Bigger or smaller power spindles (6kw or 5.5kw) 3. High-grade cooling system (chiller, it has alarming system) 4. double-head or more heads 5. servo motors (China brand or Japan brand) 6. Auto tool change system (this system need other systems accordingly, like LNC control system, servo motors etc) 7. Mach3/Nc studio controller
