Cutting scope

3000mmX1500mm / 2500x1300mm other size can be customed

Cutting Speed(max)

120m/Min

Cooling model

Water cooling with high precision constant temperature water chiller

Laser power

1500w/3000w/6000w/12000w/20000w/30000w/40000w/60000w

Fiber laser generator

Chinese Raycus/ Chinese MAX / USA IPG

Laser head

USA  Lasermech / Germany Precitec

Control system

FS full-closed loop servo control

Software

Cypcut  /Raytools

Auto Adjustor tracking

Raytools BM110

Linear guide

Imported HIWIN

Rack gear

Germany Altlanta

Low speed gear

Germany Neugart

Table

Fixed knife strip / pallet working table

Length of laser power

1080nm

Laser input power

<5KW

Cutting Thickness

0.2mm-10mm

Drive method

Imported Japan Yaskawa or China Leadshine high-precision servo drive

Transmission system

Imported high-precision TBI ball screw  / gear rack driving

Electricity demand

380V  3 phase 50 - 60HZ

Format supported

PLT, DXF, AI etc

Other standard collocation

Metal nesting software, dual-pressure gas route of 3 kind gas sources, dynamic focus and remote controller, etc

Continuous Operating Hours

24h

Machine weight

Approximate 2500KG
