2.1300x2500x200mm working table(option:1500x3000mm,2000x3000mm,2000x4000mm or according your requirements)

3.Z axis adopts Taiwan TBI ball screw transmission,high accuracy

4.Hiwin linear guide rail from Taiwan,the quality are much better

5.Gantry moving,The position precision is much better.

6.3.2kw water cooling spindle,good cooling effect,low noise.(option:4.5KW,5.5kw ,

    6kw,9kw air cooling spindle,long using life,easy to installation and operation)

7.Chinese famous stepper motor and driver,(option:Hybrid servo motor or servo motor)

8.Fuling inverter,(option:Delta inverter,well control frequency and adjust spindle speed)

9.NC-Studio control system.(option:DSPMach3/Syntec control system)

10.Emergency alarm system,ensure the operators safety

11.Dust collector ,ensure the working environment clear

12.this machine with water tank

13.Voltage:380v/50hz/3 phase or 220v/50hz/single phase

14.Option:vacuum pump,dust collector
